Control Options
- Standalone - no CanBUS communication
- Integrated CanBUS - MHD, BM3, MGF
- Advanced CanBUS - EcuTek and MHD+
Sequential Port Injection
- Up to 8 cylinders
- Real-time injector status and diagnostics
Inputs
- 1 Digital 0-500kHz for Ethanol (output over CanBUS)
- 1 Digital 0-20kHz for Crank Signal
- 1 Digital 0-20kHz for Cam Signal
- 1 Analog 0-5v ~6Hz Low-Pass MAP Sensor
- 1 Analog 0-5v ~6Hz Low-Pass Sensor
- 1 Analog 4-20mA current ~30Hz Low-Pass Fuel Pressure
- 1 Analog 4-20mA current ~30Hz Low-Pass Pressure Sensor
Outputs
- 2 Low-Side, 0-1000Hz, 4A cont, 8A max
- 2 Low-Side, 0-1000Hz, 3A cont, 6A max
- 1 Digital to Analog Expanision
- CanBUS Lo/High Comms
